39m. LOA Trawler

Length overall 39m
Length BP 31,50m
Breadth 9m
Depth to upper deck 6,10m
Depth to main deck 3,90m
Draft 3,70m
Crew 16
Tonnage 432GT
Aft fish hold capacity 152m3
Forward fish hold capacity 79m3
Net fuel oil capacity 160m3
Net fresh water capacity 109m3
Net main tanks hydraulic oil capacity 7m3
Auxiliary tanks hydraulic oil capacity 5m3
Hydraulic lub oil capacity 5m3



Trawlers

Peix Mar XXVII

33.53 m. LOA Freezer Trawler Length overall 33,53m Length BP 28m Breadth 8m Moulded depth to main deck 3,60m Moulded depth to upper deck 5,75m Moulded draft 3,00m Project trim 0,90m3 Crew 20 Fueloil capacity 20000L aprox Fresh water capacity 14m3 Oil capacity 3m3 Hold...

Radiant

36m. LOA Trawler Length overall 33m Length BP 28,75m Moulded breadth 10,50m Moulded depth to main deck 6,85m Fueloil capacity 110m3 aprox Fresh water capacity 35m3 aprox Oil capacity 1,50m3 aprox Hold capacity 300m3 aprox Crew 10 Flag Escocia...

Ellie Adhamh

25m. LOA Trawler Length overall 25m Length BP 20,90m Breadth 7,50m Depth 4,20m Fueloil capacity 40000L aprox Fresh water capacity 5000L aprox Lubricating oil capacity 500L aprox Hidraulic oil capacity 1000L aprox Fish hold capacity 130m3 aprox Ice stowage 10-15Tn Flag...

Buddy M

20 m. LOA Trawler Length overall 23,22m Length BP 18m Moulded breadth 6,20m Moulded depth to main deck 2,90m Moulded draft 2,46m Project trim 0,90m Fueloil capacity 44m3 aprox Fresh water capacity 10m3 aprox Oil capacity 1,5m3 aprox Hold capacity 42m3 aprox Crew 8...
